Heavy Duty/Jumbo Winder
Precision Winding for Large-Scale Production
The AHDW Heavy-Duty Winder is engineered for high-performance winding, seamlessly operating online with extrusion plants to produce large polypropylene packages up to 18 kg. Designed for maximum efficiency and durability, it ensures smooth, precise winding for demanding industrial applications.
Optimized for:
- Baler Twine – Ensuring strong, uniform winding for reliable performance.
- Dan Line – Delivering high-tensile strength and consistency for industrial use.
Built for power, precision, and productivity, the AHDW Jumbo Winder is the ideal choice for manufacturers looking to maximize efficiency and reduce downtime in large-scale production.
Key Features
Precision Cross Winding for uniform and consistent package formation.
Independent On/Off Switch with Speed Controller for each spindle, ensuring precise control.
Direct Extruder Feed Integration for seamless, real-time operation.
Durable Hardened Steel Traverse Cam for extended lifespan and smooth performance.
Adjustable Winding Tension with a spring-loaded dancer arm for optimal control.
Independent Traverse System for enhanced winding accuracy.
Heavy-Duty 3-Phase Torque Motor for powerful and efficient operation.
Reinforced Timing Belt, Pulley & Gear System Drive for high durability and reliability.
Low Noise Operation for a smoother, quieter working environment.
Energy-Efficient Design that minimizes power consumption while maximizing performance.
| Technical Data | Specifications |
|---|---|
Winding process |
Cross winding |
Frame |
3-tier |
Winding speed Max. |
200 m/min |
Winding ratio |
MECHANICAL gears |
Traverse length Max. |
300 mm |
Package diameter Max. |
Up to 300 mm |
Tubes ID |
54 mm X 60 mm (ID X OD) Length: 350 mm |
